Stability Index Mapping (SINMAP) Calculator for Agroforestry Treatment

Can tree planting increase slope stability?

This calculator evaluates slope stability using the SINMAP algorithm (see the SINMAP manual), which includes a root cohesion parameter Cr (N/m²). Cr can be changed according to the chosen plant species, and the calculator returns the Stability Index (SI).

SI ranking

SI > 1.5Stable slope zone

1.5 – 1.25Moderately stable zone

1.25 – 1.0Quasi-stable zone

1.0 – 0.5Lower threshold zone

0.5 – 0.0Upper threshold zone

< 0.0Defended slope zone

Stability Index 1.69

Treatment efficiency comparing to the bare slope (Cr = 0) +0.0%

Stable slope zone

Root cohesion

Root cohesion, Cr 0 N/m²

Hillslope and soil parameters

Slope angle, θ 30 deg

Soil thickness, h 0.6 m

Wetness (saturation), W 0.50

Soil cohesion, Cs 5000 N/m²

Friction angle, φ 30 deg

Density ratio, r 0.50

Default parameters for the hillslope and soil properties in this calculator were taken, as an example, from the SINMAP modeling conducted for the Nuru International Ethiopia project.
